- Description
| Mount | Ultra compact single axis EQ |
| Payload (MAX) | 6.6 lbs (3kg) |
| Mount weight | 685 gm with battery |
| Mount weight with base | 1150 gm (2.53 lbs) with battery |
| Body material | Die-cast aluminum with ABS cover |
| RA shaft | 25mm, steel |
| Worm wheel | 74mm, 144 teeth aluminum alloy |
| Worm gear | 11mm, brass |
| Worm period | 600 sec |
| Bearing | 4 pieces |
| Motor drive | DC servo |
| Tracking | R.A. automatic |
| Tracking speed | 1X Cel, 1/2 Cel, solar, lunar, N/S |
| Fast slew speed | 180X, forward and reverse |
| Polar sight hole | ~ 8º FOV |
| Polar scope | 6º FOV, dark field illuminated (8 adjustable intensity) |
| Power requirement | Internal rechargeable battery |
| Battery type | Li-Poly, 3.7V, 2000mAh |
| Duration of operation | Over 24 hours at 20ºC |
| Power charge port | Micro USB (5V), 80% charge in 5 hours |
| Body dimension | 115x115x95 mm |
| Operation Temperature | -15~40ºC |
| Mounting ring | Ø53 mm, 3/8 or 1/4" post threads |
| Body-base connection | Vixen dovetail, 3/8 socket w/ 1/4 converter |
| Alt-Azi adjustable Base | Vixen style saddle, 3/8 socket (1/4" converter) |
| Latitude adjustment range | -30º ~ 65º (with Alt-azi base) |
| AZ adjustment range | ±5° |
| Base diameter | 80 mm |
| Warranty | One year limited (90 day on battery) |
