CGX-L EQUATORIAL 925 SCHMIDT-CASSEGRAIN TELESCOPE

CelestronSKU: 12070
No reviews

Price:
Sale price$8,338.99
Stock:
Re-stocking soon
  • Description
  • Specifications

Celestron's newly designed CGX-L Computerized Equatorial mount is the latest addition to our fully computerized equatorial mount series. Capable of carrying Celestron’s largest optical tubes with ease, CGX-L is designed for backyard observatories and remote imagers looking for exceptional load capacity to weight ratio, compact design, and innovative features that fully support large telescopes, imaging kits, and the latest in wireless tech accessories.

Key design goals included larger 144 mm diameter worm wheels which provide smoother operation and can more accurately drive heavier loads, longer 270 mm dovetail saddle to support larger optical tubes, remote operation friendly features such as home and limit optical sensors, easier polar alignment adjustments, and better cable management overall. In addition to that, we’ve made mechanical and ergonomic improvements throughout to make the mount sturdier, easier to use, and easier to transport. COMPACT. ERGONOMIC. INNOVATIVE.


  • 9.25" Schmidt-Cassegrain Optical Tube Assembly
  • Aluminum Optical Tube
  • Celestron's premium StarBright XLT coatings
  • 2350 mm focal length (f/10)
  • 25 mm eyepiece included (94x)
  • Visual back allows for use with 1.25" accessories
  • 6x30 finderscope to help accurately find objects
  • Star diagonal provides more comfortable viewing position when observing objects that are high in the sky
  • Includes dovetail rail compatible with CGE mount
OPTICAL TUBE INFO:
Optical DesignSchmidt-Cassegrain
Aperture235mm (9.25")
Focal Length2350mm (93")
Focal Ratiof/10
Focal Length of Eyepiece 125mm (.98")
Magnification of Eyepiece 194x
Finderscope6x30
Star Diagonal1.25" Star Diagonal
Optical TubeAluminum
Highest Useful Magnification555x
Lowest Useful Magnification34x
Limiting Stellar Magnitude14.4
Resolution (Rayleigh)0.59 arc seconds
Resolution (Dawes)0.49 arc seconds
Light Gathering Power (Compared to human eye)1127x
Secondary Mirror Obstruction85mm (3.35")
Secondary Mirror Obstruction by Diameter36%
Secondary Mirror Obstruction by Area13%
Optical CoatingsStarBright XLT
Optical Tube Length559mm (22")
Optical Tube Diameter271.78mm (10.7")
Optical Tube Weight20 lbs (9.07 kg)
DovetailCGE Dovetail Bar
MOUNT INFO:
Mount TypeComputerized Equatorial
Instrument load capacity75 lbs (34 kg)
Height adjustment range (includes mount and tripod)908.05mm - 1339.85mm (35.75" - 52.75")
Tripod Leg Diameter69.85mm (2.75") Steel tripod with graduated markings on lower section
Latitude adjustment range3° - 65°
Mount Head Weight52.6 lbs (23.8 kg)
Accessory TrayYes
Tripod Weight46.2 lbs (21 kg)
Weight of Counterweights1 x 22 lbs
Slew Speeds9 slew speeds - max speed 3°/second
Tracking RatesSidereal, Solar and Lunar
Tracking ModesEQ North & EQ South
GPSN/A
Dovetail CompatibilityDual saddle plates (Vixen and CGE saddle)
Number of Auxiliary ports4 Aux ports (Hand Control can use any Aux port, 2 are located near dovetail saddle)
Autoguide portYes, 2 ports (one is located near the dovetail saddle)
USB PortYes, input for Mount and Hand Control
Power Requirements12V DC, 3 amps
Motor DriveDC servo motors
Alignment Procedures2-Star Align, 1-Star Align, Solar System Align, Last Alignment, Quick Align
Periodic Error CorrectionYes
Computerized Hand ControlDouble line, 16 character Liquid Crystal Display; 19 fiber optic backlit LED buttons, USB 2.0 port for PC connection
NexStar+ Database40,000+ objects, 100 user defined programmable objects. Enhanced information on over 200 objects
SoftwarePWI Telescope Control Software, Celestron's Starry Night Special Edition Software, SkyPortal App
Total Kit Weight140.8 lbs (63.86 kg)
Included ItemsCGX-L Equatorial Head | CGX-L Tripod | Accessory Tray | 1 x 22 lbs counterweight | NexStar+ Hand Control | DC Power Cable (item# 18769) | 8mm Allen wrench (contained in rear carry handle)
