Specification:
Sensor: 1/1.2" CMOS IMX174LLJ / IMX174LQJ
Resolution: 2.3Mega Pixels 1936x1216
Pixel Size: 5.86µm
Diagonal: 13.4mm
Exposure Rage: 32µs-1000s
ROI: Supported
Interface: USB3.0/USB2.0
Bit rate: 12bit output(12bit ADC)
Adaptor: 2" / 1.25" / M42X0.75
Dimension: 62mm X 41mm
Weight: 140g
Working Temperature: -5°C 45°C
Storage Temperature: -20°C 60°C
Working Relative Humidity: 20% 80%
Storage Relative Humidity: 20% 95%
Supported Resolutions:
USB3.0:
12bit ADC:
1936X1216@128FPS
640x480@309FPS
320x240@577FPS
2X2Bin : 968x608@128FPS
10bit ADC:
1936X1216@164FPS
640x480@397FPS
320x240@740FPS
2X2Bin : 968x608@164FPS
USB2.0:
1936X1216@18FPS
640x480@140FPS
320x240@560FPS
2X2Bin : 968x608@18FPS
