- Description
- Specifications
Total 10 power output ports:
19V 6A output port for mini PC*1 5-13.2V 5A switchable regulated output*2
PWM(dew heater) output port*3 (Can also be set as ordinary switchable 12V output)
Ordinary 12V switchable output port*4 Normally open 12V output*1
3*USB3.1+6*USB2.0
Built-in 12V-5V step-down module Maximum 6A continuous current USB switchable
1*DHT22 temperature & humidity sensor 3*temperature probes
（Standard accessories, no additional purchases required）
3 dew heaters independent control: Dew point temperature difference mode
Constant temperature mode
Manual mode
The 5-13.2V regulator (can be turned off) easily copes with input voltage changes and ensures stable power supply to the camera
Adjustable voltage meets the requirements of different devices.
19V 6A output is specially prepared for mini PCs (such as Intel NUCs) 120W+ peak power supply Supports high power consumption tasks such as preprocessing for images
Maximum input current 18A Powerful heat dissipation thanks to the cooling fan which automatically turns on based on power consumption.
The small magnetic silent fan produces almost no vibration
Input voltage and current monitoring 19V output current monitoring 5-13.2V regulator output current monitoring Supports current reading calibration
Electrophoresis protection
Short circuit protection
Overcurrent protection
Electrostatic protection
Maximize the security of WandererBox itself and connected devices
19V，12V and 5V power indicator lights
The working status is clear at a glance
 |
Powerful customization capabilities
Switch mode
Switch name
USB device name Dew heater mode...
|
Specifications
- Power Input - 12V DC5.5*2.1mm 8A Max
- DC Output – DC1 (5525) Always On 12V output 10A
- DC1 (5525) Always On 12V output 10A
- DC2 (5521) 19v Regulated Output Output cannot be switched on/off 6A max
- DC3-4 (5521) 0.13.2V Adjustable regulated output. Can be switched on/off together 5A max in total
- DC5,6,7 (5521) 12V PWM/Switch\Output 8Amp
- DC8-9 (5521) 12V switched output, can be switched on/off together 8A max total
- DC10-11 (5521) 12V switched output, can be switched on/off together 8A max total
- USB Hub – 3x USB3.1, 6x USB2.0 USB3.1 – 3 independent switches, USB2.0 2 sets of switch's (3+3)
- USB Power Supply – 5V 6A
- Input current/ Voltage monitor
- Size – 13.6x 8.3x 3.6 cm
- Weight 375g
- 1 x DHT22 temperature & Humidity sensor
- 3x DS18B20 temperature
- 1 dew heater:
- Dewpoint temperature difference control
- Constant tempo control
- Manual Control
- Cooling fan
- ASCOM - Yes
- Screw Holes M6 and M4 screw holes, 4mm Deep
