ZWO Optical

ASI678MC

(1 review) Write a Review
$404.00
Your Price: $372.00
ASI678MC
SKU:
ASI678MC
Adding to cart… The item has been added

Product Overview


EN--ASI678M-C_01EN--ASI678M-C_02EN--ASI678M-C_03EN--ASI678M-C_04EN--ASI678M-C_06EN--ASI678M-C_07EN--ASI678M-C_08EN--ASI678M-C_09EN--ASI678M-C_10EN--ASI678M-C_11EN--ASI678M-C_12EN--ASI678M-C_13EN--ASI678M-C_14EN--ASI678M-C_15

Specifications

  • Sensor: 1 / 1.8? CMOS Sony-IMX678AAQR1-C
  • Bayer Pattern:R Gr Gb B
  • QE peak:83%
  • Back focus length: 12.5mm
  • Max fps: 47.5fps
  • Full well: 11.27Ke
  • Shutter: Rolling shutter
  • Resolution: 8.29Mega Pixel,3840*2160
  • Pixel Size: 2µm
  • Exposure Range: 32µs~2000s
  • Interface: USB 3.0 /USB 2.0 Type-B
  • Protect window: f21-1.1 IR
  • ADC: 12bit
  • Dimension: 7.68mm*4.32mm
  • Weight: 126g
  • Working Temperature: -5?~50?
  • Storage Temperature: -10?~60?
  • Working Relative Humidity: 0-80%
  • Supported OS: WIN7/8/10 32&64?Linux?Mac
